C Band 2 port band circular polarization Duplexer

【Product introduction】:

Contains OMT, 2 duplexers, phase shifter, combiner

Features: wide working bandwidth, low insertion loss, great rejection, high Power Capacity.

Function: circular polarization T/R mode:  Same/different frequency;1/2 polarization Circular polarization T/R mode:  Same/different frequency; LHCP/RHCP polarization (by adding circular polarizer).

【Technical indicators】:

1. Working frequency: RX: 3.40GHz~4.80GHz;

   TX: 5.85GHz~7.250GHz;

2. VSWR: 1.25:1 MAX

3. Insertion loss: 0.40dB MAX

4. Isolation: TX/RX: 95dB MIN

5. Cross polarization: 40dB MIN

6. Axial ratio: 1.5dB MAX

7. Power Capacity: 200W(CW)

8. Interface: WR229(RX),WR137(TX)

9. Structure:
